 |  |  |  |  |  |  |  | Notes Bulletin Reference | |||
| 050H0705 | 1 | + | Column Assembly | Upto Chassis No. 0928 | |||||||
| 050H0706 | 1 | + | Column Assembly | Upto Chassis No. 0928 | |||||||
| 026H0705 | 1 | 1 | 1 | 1 | + | Column Assembly, Without Lock | From Chassis No. 0929 | ||||
| 026H0706 | 1 | 1 | 1 | 1 | + | Column Assembly, Without Lock | From Chassis No. 0929 | ||||
| A036H0063 | 1 | 1 | 1 | 1 | Clip - Blanking, Without Lock | From Chassis No. 0929 | |||||
| 050H0723 | 1 | + | Column Assembly, With Lock | From Chassis No. 1614 | |||||||
| 050H0724 | 1 | + | Column Assembly, With Lock | From Chassis No. 1614 | |||||||
| 050H0730 | 1 | 1 | 1 | + | Column Assembly, With Lock | From ? | |||||
| 050H0731 | 1 | 1 | 1 | + | Column Assembly, With Lock | From ? | |||||
| 2 | 050H0040 | 1 | Column - Inner | Upto ? | |||||||
| A050H0040 | 1 | Column - Inner (With Lock) | From ? | ||||||||
| B050H0040 | 1 | Column - Inner (With Lock) | From ? | ||||||||
| 3 | 050H0722 | 1 | Column - Outer | Upto ? | |||||||
| A050H0722 | 1 | Column - Outer (With Lock) | From ? | ||||||||
| B050H0722 | 1 | Column - Outer (With Lock) | From ? | ||||||||
| 4 | 050H6001 | 2 | Bush - Column | ||||||||
| 5 | 050H6005 | 1 | Clamp - Column to Body | ||||||||
| 050H0051 | 1 | + | Bracket - Column Mounting | ||||||||
| 050H0052 | 1 | + | Bracket - Column Mounting | ||||||||
| XUFS0412 | 3 | Screw, Bracket to Body | |||||||||
| A04W1606 | 3 | Washer, plain, Bracket to Body | |||||||||
| L04W0000 | 3 | Washer , shakeproof, Bracket to Body | |||||||||
| XUFS0448 | 2 | Screw, Column to Bracket | |||||||||
| 050H0053 | AR | Spacer, Column to Bracket | |||||||||
| A04W0905 | 2 | Washer, Column to Bracket | |||||||||
| YUFN040F | 2 | Nut, Column to Bracket | |||||||||
| 7 | 050H6006 | 1 | + | Binnacle - Upper | |||||||
| 050H6009 | 1 | + | Binnacle - Upper | ||||||||
| 8 | 050H6007 | 1 | + | Binnacle - Lower | |||||||
| 050H6010 | 1 | + | Binnacle - Lower | ||||||||
| 050H6008 | 4 | Screw - Binnacle | |||||||||
| 9 | 050M6020 | 1 | + | Switch - Dip/Indicators/Horn | |||||||
| 050M6019 | 1 | + | Switch - Dip/Indicators/Horn | ||||||||
| 11 | 036H6055 | 1 | 1 | 1 | 1 | 1 | Inner Column - Lower | ||||
| 036H6056 | 1 | 1 | 1 | 1 | Inner Column - Upper | ||||||
| 12 | 036H0072 | 1 | 1 | 1 | + | Inner Column - Upper | |||||
| 036H0073 | 1 | 1 | 1 | + | Inner Column - Upper | ||||||
| 13 | 036H6038 | 1 | 1 | 1 | 1 | 1 | Clamp - Upper to Lower Column | ||||
| 036H6057 | 1 | 1 | 1 | 1 | 1 | Screw, Clamp Fixing | |||||
| 036H6058 | 1 | 1 | 1 | 1 | 1 | Washer, Clamp Fixing | |||||
| 036H6000 | 1 | 1 | 1 | 1 | Outer Column | ||||||
| 14 | 036H0074 | 1 | 1 | 1 | + | Outer Column | |||||
| 036H0075 | 1 | 1 | 1 | + | Outer Column | ||||||
| 15 | 036H6031 | 2 | 2 | 2 | 2 | 2 | Bush - Column | ||||
| KSTS0810 | 4 | 4 | 4 | 4 | 4 | Screw, Outer Column to Facia | |||||
| A03W0605 | 4 | 4 | 4 | 4 | 4 | Washer, Outer Column to Facia | |||||
| 16 | 036H6053 | 1 | 1 | 1 | 1 | 1 | Escutcheon | ||||
| 036H6033 | 1 | 1 | 1 | 1 | 1 | Escutcheon | |||||
| KSTS0410 | 4 | 4 | 4 | 4 | 4 | Screw - Escutcheons | |||||
| 17 | 036G6009 | 1 | 1 | 1 | 1 | 1 | Connector - Horn Push | ||||
| 18 | 050H2000 | 1 | 1 | Steering Wheel | |||||||
| 050H2000B | 1 | 1 | 1 | Steering Wheel | |||||||
| 19 | 036H6008 | 1 | 1 | 1 | 1 | 1 | Clip - Horn Push | ||||
| 20 | 036H6035 | 1 | Nut - Wheel to Column | ||||||||
| 21 | 028M0705 | 1 | 1 | 1 | 1 | 1 | Brush - Horn Connector | ||||
| 22 | 028H0030 | 1 | Horn Push | ||||||||
| 23 | 050M6071 | 1 | 1 | 1 | 1 | 1 | Switch - Headlamps | ||||
| 24 | 050M6072 | 1 | 1 | 1 | 1 | 1 | Switch - Headlamps | ||||
| 25 | 050H0054 | 1 | Plate - Retaining - Seal | ||||||||
| 050H0055 | 1 | Seal - Column | |||||||||
| 26 | B050H0055 | 1 | 1 | 1 | 1 | Seal - Column | |||||
| 036B6123 | 2 | Tappit - Plate to Body | |||||||||
| 27 | A036H6064 | 1 | Steering Lock (with buzzer) | ||||||||
| 28 | A036H6055 | 1 | 1 | Steering Lock (with buzzer) |
