 |  |  |  |  |  |  |  | Notes Bulletin Reference | |||
| 1 | 050B0129 | 1 | 1 | 1 | 1 | Cylinder Vacuum - LH | Upto 1362 only | ||||
| 2 | 050B0124 | 1 | 1 | 1 | 1 | Cylinder Vacuum - RH | Upto 1362 (Federal Cars only) | ||||
| 3 | YUFN040F | 2 | 2 | 2 | 2 | Nut, Vacuum Cylinder to Body | Upto 1362 (Federal Cars only) Upto 1451 all except Federal | ||||
| 4 | A04W1606 | 1 | 1 | 1 | Washer, Vacuum Cylinder to Body | Upto 1362 (Federal Cars only) Upto 1451 all except Federal | |||||
| A04W1606 | 1 | 1 | 1 | Washer, RH Vacuum Cylinder to Body | From 1452 | ||||||
| YUFN040F | 1 | 1 | 1 | 1 | Nut, RH Vacuum Cylinder to Body | From 1452 | |||||
| 5 | 026B0117 | 1 | 1 | 1 | 1 | Spring - Headlamp Return - LH | Upto 1362 (Federal Cars only) | ||||
| 6 | 026B0118 | 1 | 1 | 1 | 1 | Spring - Headlamp Return - RH | Upto 1362 (Federal Cars only) | ||||
| 7 | 026B0122 | 2 | 2 | 2 | 2 | Distance Tube, Spring and Vacuum Cylinder to Headlamp Bowl | Upto 1362 (Federal Cars only) | ||||
| 8 | XUFB0420 | 2 | 2 | 2 | 2 | Bolt, Spring and Vacuum Cylinder to Headlamp Bowl | Upto 1362 (Federal Cars only) | ||||
| 9 | YUFN040F | 2 | 2 | 2 | 2 | Nut, Spring and Vacuum Cylinder to Headlamp Bowl | Upto 1362 (Federal Cars only) | ||||
| 10 | A06W0904 | 4 | 4 | 4 | 4 | Washer, Spring and Vacuum Cylinder to Headlamp Bowl | Upto 1362 (Federal Cars only) | ||||
| 11 | A06W1207 | 6 | 6 | 6 | 6 | Washer, Spring and Vacuum Cylinder to Headlamp Bowl | Upto 1362 (Federal Cars only) | ||||
| 12 | 050B1313 | 2 | 2 | 2 | 2 | Mounting Bracket - Vacuum Cylinder to Body | Upto 1362 (Federal Cars only) | ||||
| 050B1313 | 1 | 1 | 1 | Mounting Bracket - Vacuum Cylinder to Body | From 1452 | ||||||
| 13 | XUFB0412 | 4 | 4 | 4 | 4 | Screw, Mounting Bracket to Body | Upto 1362 (Federal Cars only) | ||||
| 14 | YUFN040F | 4 | 4 | 4 | 4 | Nut, Mounting Bracket to Body | Upto 1362 (Federal Cars only) | ||||
| 15 | A04W1606 | 4 | 4 | 4 | 4 | Washer, Mounting Bracket to Body | Upto 1362 (Federal Cars only) | ||||
| 16 | AUFN040F | 2 | 2 | 2 | 2 | Nut, Vacuum Cylinder to Bracket | Upto 1362 (Federal Cars only) | ||||
| 17 | S04W0000 | 2 | 2 | 2 | 2 | Washer, Vacuum Cylinder to Bracket | Upto 1362 (Federal Cars only) | ||||
| 18 | 026B0736 | 1 | 1 | 1 | 1 | Valve - Headlamp Operating | Upto 1362 (Federal Cars only) | ||||
| 19 | 036B6008 | 1 | 1 | 1 | 1 | Knob - Headlamp Operating Valve | |||||
| 20 | J019 | 1 | 1 | 1 | 1 | 'T' Piece | |||||
| 21 | 036B0136 | 1 | 1 | 1 | 1 | Non-Return Valve | |||||
| 22 | 050B0133 | 1 | 1 | 1 | 1 | Nylon Pipe 24 ins. long | Upto 1362 (Federal Cars only) | ||||
| 23 | 050B0130 | 1 | 1 | 1 | 1 | Nylon Pipe 14 ins. long | |||||
| 026B0130 | 1 | Nylon Pipe 25 ins. long | |||||||||
| 24 | 050B0131 | 1 | 1 | 1 | 1 | Nylon Pipe 76 ins. long | |||||
| A050B0131 | 1 | Nylon Pipe 63 ins. long | |||||||||
| 25 | 050B0132 | 1 | 1 | 1 | 1 | Nylon Pipe 72 ins. long | |||||
| A050B0132 | 1 | Nylon Pipe 59 ins. long | |||||||||
| 036B6009 | AR | 'P' Clip | |||||||||
| 036B6026 | AR | Screw, Vacuum Pipes to Body | |||||||||
| 036B6001 | AR | Nut, Vacuum Pipes to Body | |||||||||
| 26 | A036B6181 | AR | Sleeve - Vacuum Pipes | ||||||||
| 27 | 036B6010 | 2 | Grommet - Vacuum Pipes | ||||||||
| 28 | XUCS0420 | 4 | Bolt, Headlamp Bowls to Bobbins | Upto 1362 (Federal Cars only) | |||||||
| 29 | L04W0000 | 4 | Washer, Headlamp Bowls to Bobbins | Upto 1362 (Federal Cars only) | |||||||
| 30 | XUCS0432 | 4 | Screw, Headlamp Stop | ||||||||
| 31 | AUCN040F | 4 | Nut, Headlamp Stop | ||||||||
| 32 | 026E0367 | 1 | 1 | 1 | 1 | Union - Non Return Valve | |||||
| 33 | 036M6023 | 1 | Microswitch (replaced by 2 off 050M6066 together with: 4 off 050M6067 - L Nut 1 off A050B1234 - Mounting Bracket) | Upto 0444 | |||||||
| 050B6066 | 2 | Microswitch - Headlamps | From 0445 | ||||||||
| 050B6066 | 2 | 2 | 2 | Microswitch - Headlamps | Upto 1362 (Federal Cars only) Upto 1891 (Other Territories) | ||||||
| A050M6180 | 1 | 1 | Microswitch - Headlamps | From June 1970 | |||||||
| 34 | 050B1234 | 1 | Mounting Bracket | Upto 0444 | |||||||
| A050B1234 | 1 | 1 | Mounting Bracket | From 0445 (Other Territories) From 0445 to 1362 (Federal Cars only) | |||||||
| A050B1234 | 1 | 1 | Mounting Bracket | Upto 1891 | |||||||
| 35 | 036B0492 | 2 | 2 | 2 | 2 | Downstop - Headlamp | |||||
| 036B6030 | 2 | Buffer - Downstop | |||||||||
| 36 | LUCN040F | 2 | 2 | 2 | 2 | Lock Nut | |||||
| 054B6000 | 1 | 1 | Microswitch - Sidelamps | ||||||||
| 050B1768 | 2 | 2 | Mounting Bracket | ||||||||
| 050M6097 | 2 | 2 | Lock Nut | From 1892 | |||||||
| AUCN040M | 2 | 2 | Lock Nut, Bracket to Downstop | From 1892 | |||||||
| A04W0904 | 1 | 1 | Washer, Bracket to Downstop | From 1452 | |||||||
| 37 | 050B1741 | 1 | 1 | 1 | Mounting Bracket - Vacuum Cylinder to Body | From 1452 | |||||
| XUFS0308 | 4 | 4 | 4 | Screw, LH Vacuum Cylinder Mounting Bracket to Body | From 1452 | ||||||
| YUFN030F | 4 | 4 | 4 | Nut, LH Vacuum Cylinder Mounting Bracket to Body | From 1452 | ||||||
| A03W1606 | 4 | 4 | 4 | Washer, LH Vacuum Cylinder Mounting Bracket to Body | From 1452 | ||||||
| A26B736 | - | - | Valve (replaced by A026B0736A) | ||||||||
| 38 | A026B0736A | 1 | 1 | Valve - Headlamp Operating | From 1363 | ||||||
| 36M6274 | - | - | Microswitch (replaced by 050M0124) | From 1363 | |||||||
| 39 | 050M0124 | 2 | 2 | Microswitch - Headlamps | From 1363 | ||||||
| 40 | 036B1675 | 1 | 1 | Mounting Plate | From 1363 | ||||||
| 036B1676 | 1 | 1 | Operating Show | From 1363 | |||||||
| 41 | 036B1664 | 1 | 1 | Vacuum Cylinder | From 1363 | ||||||
| 42 | 036B1673 | 1 | 1 | Mounting Plate - Vacuum Cylinder | From 1363 | ||||||
| XUFS0412 | 4 | 4 | Screw, Mounting Bracket to Body | From 1363 | |||||||
| YUFN040F | 4 | 4 | nut, Mounting Bracket to Body | From 1363 | |||||||
| A04W1606 | 4 | 4 | Washer, Mounting Bracket to Body | From 1363 | |||||||
| 43 | A04W1609 | 1 | 1 | Washer, Vacuum Cylinder to Mounting Bracket | From 1363 | ||||||
| 44 | YUFN040F | 1 | 1 | Nut, Vacuum Cylinder to Mounting Bracket | From 1363 | ||||||
| 45 | 026B0117 | 1 | 1 | Spring - Headlamp | From 1363 | ||||||
| 46 | 036B0118 | 1 | 1 | Spring - Headlamp | From 1363 | ||||||
| 036B0117 | 1 | 1 | Spring - Headlamp, Optional in pairs to 026B0117 & 036B0118 | From 1363 | |||||||
| 026B0118 | 1 | 1 | Spring - Headlamp, Optional in pairs to 026B0117 & 036B0118 | From 1363 | |||||||
| 47 | UFS0420 | 1 | 1 | Screw, Spring and Vacuum Cylinder Rod to Headlamp Operating Rod | From 1363 | ||||||
| 48 | A04W1606 | 2 | 2 | Washer, Spring and Vacuum Cylinder Rod to Headlamp Operating Rod | From 1363 | ||||||
| 49 | YUFN040F | 1 | 1 | Nut, Spring and Vacuum Cylinder Rod to Headlamp Operating Rod | From 1363 | ||||||
| 50 | 050B1658 | 1 | 1 | Operating Rod | From 1363 | ||||||
| 51 | XUCS0432 | 2 | 2 | Screw, Headlamp Bowl to Bobbin | From 1363 | ||||||
| 52 | L04W0000 | 2 | 2 | Washer, Headlamp Bowl to Bobbin | From 1363 | ||||||
| 53 | XUFS0412 | 2 | 2 | Screw, Link Bar to Headlamp Bowl | From 1363 | ||||||
| 54 | A04W1606 | 4 | 4 | Washer, Link Bar to Headlamp Bowl | From 1363 | ||||||
| 55 | YUFN040F | 2 | 2 | Nut, Link Bar to Headlamp Bowl | From 1363 | ||||||
| 56 | 036J0135 | 2 | 2 | Elbow | From 1363 |
