ELITE/ECLAT PARTS MANUAL

Section FH -- Gearbox - Getrag 5 Speed - Gear Linkage & Mounting


PLATE Ref. No.	DESCRIPTION	PART NO.					REMARKS
	Mounting Rubber, Gearbox	A083F6001F	*	*	*	2
	Bolt, M10 x 65, Rubber to Gearbox	A075W20567	*	*	*	2
	Nut, Nyloc, M10, R.H. Rubber to Gearbox	A075W3011Z	*	*	*	1
	Nut, Plain, M10, L.H. Rubber to Gearbox	A075W3023F	*	*	*	1	Stainless. Use Permabond
	Washer, 10 mm, Gearbox height adiust	A075W4027Z	*	*	*	8
	Crossmember, Gearbox Mounting	A083F0384J	*	*	*	1
	Setscrew, M8 x 20, Rubber/Crossmember	A075W1038Z	*	*	*	4
	Nut, Nyloc, M8, R.H. Rubber/Crossmember	A075W3010Z	*	*	*	2
	Nut, Plain, M8, L.H. Rubber/Crossmember	A075W3022Z	*	*	*	2	Stainless. Use Permabond
	Washer, 8 mm, Rubber/Crocsmember	A075W4020Z	*	*	*	4
	Washer, Spring, 8 mm, Rubber Crossmember	A075W4036Z	*	*	*	4
	Spacer, Crossmember/Chassis	A083F0389K	*	*	*	AR
	Setscrew, M8 x 20, Crossmember/Chassis	A075W1038F	*	*	*	4
	Washer, 8 mm, Crossmember/Chassis	A075W4020Z	*	*	*	4
	Heatshield, L.H. Mounting	B083F0390F	*	*	*	1
	Screw, s/t Heatshield Fix	A075W5014Z	*	*	*	2
	Washer, Heatshield Fix	A075W4073Z	*	*	*	2
	Damper, Lower, Tailshaft Housing	A083F0379J	*	*	*	1	Prior to introduction ? 'Flexplate Flywl ?
	Bolt, M10 x 100, Damper to Housing	A075W2062Z	*	*	*	2	Prior to introduction ? 'Flexplate Flywl ?
	Washer, 10 mm	A075W4024Z	*	*	*	2	Prior to introduction ? 'Flexplate Flywl ?
	Damper, Upper, Tailshaft Housing	A083F0378J	*	*	*	1
	Setscrew, M8 x 40, Damper/Housing	A075W1039Z	*	*	*	2
	Washer, 8 mm	A075W4020Z	*	*	*	2
	Fulcrum Bracket	B083F0362	*	*	*	1
	Bolt, M8 x 55, Fulcrum Bracket/Housing	A075W2042F	*	*	*	2
	Washer, 8 mm, Fulcrum Bracket/Housing	A075W4020Z	*	*	*	2
	Pivot Plate	B083F0361	*	*	*	1
	Rubber Bush, Pivot Plate front	A083F6085	*	*	*	2
	Setscrew, M8 x 25, Socket Head	A075W7024Z	*	*	*	2	Pivot Plate/Fulcrum B *?
	Rubber Bush, Pivot Plate rear	A083F6086	*	*	*	1
	Nut, M8t Pivot Plate/Rear Bush	A075W3021Z	*	*	*	2
	Washer, 8mm	A075W4020Z	*	*	*	2
	Gear Lever	C083F0357	*	*	*	1	Includes Roller Bearin *?
	Roller Bearing, Gear Lever Eye	A083F6228F	*	*	*	2
	Knob, Gear Lever	A083F0323	*	*	*	1
	Gaiter, Lower, Gear Lever	A076V1444F	*	*	*	1
	Ring, Gaiter retaining	A075U0622Z	*	*	*	1
	Screw, s/t	A075W1035	*	*	*	1
	Plate, Gear Lever Aperture	B083F0368	*	*	*	1
	Screw, s/t	A075W5031	*	*	*	1
	Circlip, Gear Lever to Pivot Plate	A083F6083	*	*	*	1
	'O' Ring, Gear Lever to Pivot Plate	A083F6084	*	*	*	1
	Pin, Gear Lever to Yoke	A083F6076	*	*	*	1
	Spring Clip, Pin retaining	A083F6077	*	*	*	1
	'0' Ring, Yoke to Gear Lever	A083F6075	*	*	*	1
	Yoke	A083F6074	*	*	*	1
	Actuating Rod	A083F0359	*	*	*	1
	Screw, Actuating Rod to Yoke	A083F6078	*	*	*	1
	Link, Connecting	A083F6079	*	*	*	1
	Pad, Felt, Actuating Rod/Main Selector Shaft	A083F6081	*	*	*	1
	Pin, Connecting, Link/Rod Shaft	A083F6080	*	*	*	1
	Sleeve, Pin retaining	A083F6082	*	*	*	1
*? - Indicates that text was missing from the document used to create this page. -- Contact the Webmaster with corrections.
