Elite/Eclat Parts Manual -- Section PD

ELITE/ECLAT PARTS MANUAL

Section PD -- Heater Unit (Lotus)


PLATE Ref. No.	DESCRIPTION	PART NO.								REMARKS
	Heater Assembly (inc. Slide Controls and Water Valve)	A075P0712J	*	*			*	*	1	Unit Nos 0728A to 0797A an ? 0806A on, 0115C on, 0134C ? 0146D to 0181D and 0191D ? 0125E, 0126E and 0128E on, ? 0107F on. All inc.
	Heater Assembly (inc. Rotary Controls and Water Valve)	A083P0715			*	*	*	*	1
	Heater/Air Conditioning Assembly (inc. Slide Controls and Water Valve)	A075P0713J	*	*			*	*	1	Unit Nos. 0746A, 0773A to ? 0795A. 0848A to 0850A and ? 0859A on. 0456B and 0467B ? 0116C on. 0147D, 0170D an ? 0173D on. 0114E on. 0105 *? All nos inc.
	Heater/Air Conditioning Assembly. (inc. Rotary Controls and Water Valve)	A083P0716			*	*	*	*	1
	Setscrew, M6 x 16, Unit to Body	A075W1028	*	*	*	*	*	*	2
	Washer, Shakeproof, Unit to Body	A075W4046	*	*	*	*	*	*	2
	Washer, Large O/D, Unit to Body	A075W4017	*	*	*	*	*	*	2
	Nut, Nyloc, M8, Unit to Body	A075W3010	*	*	*	*	*	*	2
	Washer, 8mm, Unit to Body	A075W4021	*	*	*	*	*	*	2
	Foam Rubber Strip, Case Sealing	A036B6213	*	*	*	*	*	*	AR
	Edge Clip, Case Securing	A075W6060	*	*	*	*	*	*	7
	Heater Matrix	A075P6055F	*	*	*	*	*	*	1
	Foam Seal, Heater Matrix	A075P0194K	*	*	*	*	*	*	1
	Evaporator	A075P0201	*	*	*	*	*	*	1	With Air Conditioning
	Foam, Open Mesh	A075P0206	*	*	*	*	*	*	1	With Air Conditioning
	Non-Drip Tape, Evaporator Connections	A075P6086	*	*	*	*	*	*	AR
	Blower Motor and Fan, Right Hand	A075P6056F	*	*	*	*	*	*	1
	Blower Motor and Fan, Left Hand	A075P6058F	*	*	*	*	*	*	1
	Retaining Ring, Blower Motor, Right Hand	A075P0155	*	*	*	*	*	*	1
	Retaining Ring, Blower Motor, Left Hand	A075P0156	*	*	*	*	*	*	1
	Vacuum Actuator, Flaps	B075P6059	*	*	*	*	*	*	2
	Bracket, Vacuum Actuator, Face Level Flap	B075P0170	*	*	*	*	*	*	1
	Bracket, Vacuum Actuator, Fresh Air Flap	B075P0169	*	*	*	*	*	*	1
	Pop Rivet	A075W6090	*	*	*	*	*	*	8
	Washer, Pop Rivet	A075W4001	*	*	*	*	*	*	4
	Rod, Extension, Face Level Actuator	A075P0234	*	*	*	*	*	*	1
	Locking Tab	A079P4149	*	*	*	*	*	*	1
	Flap, Face Level	A075P0157	*	*	*	*	*	*	1
	Foam ź", Flap Sealing	A075P6071	*	*	*	*	*	*	AR
	Pivot, Face Level Flap	A075P0162	*	*	*	*	*	*	2
	Clip, Flap Pivot	A075W6173	*	*	*	*	*	*	2
	Lever, Face Level Flap	A075P0177	*	*	*	*	*	*	1
	Grub Screw, 10 UNF	A075W7023	*	*	*	*	*	*	1
	Clip, Flap Linkage	A075U6033	*	*	*	*	*	*	1
	Flap, Fresh Air, Right Hand	A075P0184	*	*	*	*	*	*	1
	Flap, Fresh Air, Left Hand	A075P0185	*	*	*	*	*	*	1
	Foam, ź ", Flap Sealing	A075PS071	*	*	*	*	*	*	AR
	Sleeve, Flap Spindles	A075P0167	*	*	*	*	*	*	1
	Grubscrew, Sleeve/Spindles	A075W7023	*	*	*	*	*	*	2
	Lever, Fresh Air Flaps	C075P0168	*	*	*	*	*	*	1
	Grubscrew, Lever/Splndle	A075W7023	*	*	*	*	*	*	1
	Pivot Bush, Inner	A075P6063	*	*	*	*	*	*	3
	Pivot Bush, Outer	A075P6064	*	*	*	*	*	*	3
	Push-on Fixing, Fresh Air Flaps	A075W6174	*	*	*	*	*	*	2
	Clevis Pine Vacuum Actuator to Flap Lever	A075W6144	*	*	*	*	*	*	1
	Split Pin	A075W6005	*	*	*	*	*	*	1
	Flap, Defrost	A075P0160	*	*	*	*	*	*	1
	Foam ź", Flap Sealing	A075P6071	*	*	*	*	*	*	AR
	Pivot Bush, Defrost Flap	A075P0162	*	*	*	*	*	*	2
	Clip, Push-On	A075W6173	*	*	*	*	*	*	2
	Lever, Defrost Flap Spindle	A075P0174	*	*	*	*	*	*	1
	Grub Screw, Defrost Flap Lever	A075W7023	*	*	*	*	*	*	1
	Spring, Defrost Flap Lever	B075P0176	*	*	*	*	*	*	1	Heater Only
	Spring, Vacuum Switch Cam	B075P0176	*	*	*	*	*	*	1	Air Conditioning
	Cam, Vacuum Switch Operating	A075P0173	*	*	*	*	*	*	1
	Trunnion, Cable to Camshaft	A075W6121	*	*	*	*	*	*	1
	Linkage Clips (Air Conditioning Defrost Flap)	A075U6033	*	*	*	*	*	*	4
	Vacuum Switch	A075P6062	*	*	*	*	*	*	2
	Control Cable, Distribution	A075P0228F	*	*	*	*	*	*	1	Series One-Heater only
	Control Cable, Distribution	A075P0226F	*	*	*	*	*	*	1	With Air Conditioning
	Control Cable, Temperature (Water Valve)	A075P0222F	*	*	*	*	*	*	1
	Clip, Cable Abutment	A075W6117	*	*	*	*	*	*	2
	Rotary Control, Temperature	B083P0246	*	*	*	*	*	*	1
	Rotary Control, Distribution	B083P0247	*	*	*	*	*	*	1
	Knob, Temperature/Distributor Controls	A082P6023F	*	*	*	*	*	*	2
	Micro Switch, Rotary Ternpemture Control	A075M6084F	*	*	*	*	*	*	1	With Air Conditioning
	Bracket, Micro-Switch to Control	A075M0340	*	*	*	*	*	*	1
	Screw, No. 4 x ž", Swltch/Bracket	A075W5009	*	*	*	*	*	*	2
	Washer, Switch/Bracket	A075W4001	*	*	*	*	*	*	2
	Screw, 4BA, Bracket/'Control	A075W5048	*	*	*	*	*	*	2
	Nut, 4BA, Bracket/Control	A079W3057	*	*	*	*	*	*	2
	Water Valve	A075P6060F	*	*	*	*	*	*	1
	Flexible Hose 1˝" Diameter, Footwell	A075P6066V	*	*	*	*	*	*	AR
	Flexible Hose, 2" Diameter, F.L.V.	A079P4005	*	*	*	*	*	*	AR
	Face Level Vents	A075P6018	*	*	*	*	*	*	4
	Clip, Centre Vents Retaining	B075P0115	*	*	*	*	*	*	2
	*? May be missing text here. The document used to create this page skips from page PD 4 to PD 7, missing PD 5 and PD 6.
	Hose, Heater, Engine to Connector Sleeve	A075K0119F	*	*	*	*	*	*	1
	Connector Sleeve, Heater Hose	B075K0111	*	*	*	*	*	*	1
	Hose, Heater, Connector Sleeve to Matrix	A075P0231F	*	*	*	*	*	*	1
	Hose, Heater, Matrix to Water Valve	A075P0189	*	*	*	*	*	*	1
	Hose, Heater, Valve to Connector Sleeve	A075K0119Z	*	*	*	*	*	*	1
	Connector Sleeve, Heater Hose	B075K0111	*	*	*	*	*	*	1
	Hose, ' Heater, Connector Sleeve to Water Pump	A079P4056F	*	*	*	*	*	*	1
	Clip, Heater Hose to Engine	B907E6229F	*	*	*	*	*	*	1
	Hose, 5/8" PVC, ACU Drain	A075U6083	*	*	*	*	*	*	1	500 mm length
	Hose Clip, 16-25mm, Heater Hose	A079K6018F	*	*	*	*	*	*	9
	Grommet, Hoses/Body	A075P6021	*	*	*	*	*	*	3
*? - Indicates that text was missing from the document used to create this page. -- Contact the Webmaster with corrections.
